Find Your Part (w/ Details)
| Part Number | Height | Width | Depth | Filler Neck | Product | Inlet | Outlet | Oil Cooler | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
www.activeradiator.com Call today to Order
450074 - Kubota / Ingersoll Rand Radiator Special Notes
Options / Pricing / Availability
Call for price
Call for price
Core Dimensions Height: 14.75"
Width: 16.125"
Depth: 1.4375"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 1.125" (Left) Outlet: 1.125" (Left) Oil Cooler: None OE Numbers
450074
1G97622063 1G97672112 1G97672060 4220008462 1G97672063 36888451 866110GT 245966 SCSI245966 23083405 2930015889519 015889519 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450075 - Caterpillar Generator Radiator Special Notes
Options / Pricing / Availability
Call for price
Core Dimensions Height: 25.875"
Width: 26"
Depth: 2.8125"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 2" (Left Center) Outlet: 2" (Right) Oil Cooler: None OE Numbers
450075
1N4343 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450076 - Komatsu PC228 Special Notes Very similar to 45-0908AT, please verify presence of 5/8" hose connection next to drain plug.
Options / Pricing / Availability
Call for price
Core Dimensions Height: 32.625"
Width: 13.75"
Depth: 3.688"
Overall Height: "
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 2" (Top Left) Outlet: 2" (Bottom Right) Oil Cooler: None OE Numbers
450076
11427 11413991000 22U0322111 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450077 - Sennebogen Excavator Special Notes Very similar to 4500-55 must verify mounting brackets
Options / Pricing / Availability
Core Dimensions Height: 25.5"
Width: 20"
Depth: 5.5"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: None Inlet: 2" (Top Left) Outlet: 2" (Bottom Right) Oil Cooler: None OE Numbers
450077
450077AT | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450078 - Doosan Radiator Special Notes
Options / Pricing / Availability
Core Dimensions Height: 18.625"
Width: 16.75"
Depth: 3.5"
Overall Height: -
Description Product Type: Radiator Orientation: Crossflow Filler Neck: Right Inlet: 2" (Left) Outlet: 2" (Right) Oil Cooler: Right OE Numbers
450078
D830124 A413505 20302070 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450079 - Grettir Radiator Special Notes
Options / Pricing / Availability
Core Dimensions Height: 41.1875"
Width: 14.5625"
Depth: 5.5"
Overall Height: -
Description Product Type: Radiator Filler Neck: None Oil Cooler: None OE Numbers
450079
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450080 - JCB / Case Radiator Special Notes
Options / Pricing / Availability
Call for price
Core Dimensions Height: 21.75"
Width: 24.625"
Depth: 3"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 2" (Right) Outlet: 2" (Left) Oil Cooler: None OE Numbers
450080
30925700 30925699 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450081 - Military Radiator Special Notes
Options / Pricing / Availability
Core Dimensions Height: 29.75"
Width: 28.75"
Depth: 4.1875"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Center Inlet: 2.25" (Top Left) Outlet: 3" (Bottom Right) Oil Cooler: None OE Numbers
450081
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450083 - Industrial Radiator Special Notes
Options / Pricing / Availability
Core Dimensions Height: 17.4375"
Width: 18.5625"
Depth: 2"
Overall Height: -
Description Product Type: Radiator Orientation: Crossflow Filler Neck: Right Inlet: 1.25" (Right) Outlet: 1.25" (Left) Oil Cooler: None OE Numbers
450083
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450085 - Perkins Powered Generator Radiator Serpentine Fin Core Special Notes
Options / Pricing / Availability
Call for price
Core Dimensions Height: 27.875"
Width: 22.75"
Depth: 2.25"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 2" (Left) Outlet: 2.25" (Left) Oil Cooler: None OE Numbers
450085
2485B251 20224101P | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450086 - Perkins Powered Generator Radiator Flat Fin Core Special Notes
Options / Pricing / Availability
Core Dimensions Height: 27.875"
Width: 22.75"
Depth: 2.25"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 2" (Left) Outlet: 2.25" (Left) Oil Cooler: None OE Numbers
450086
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450089 - Kobelco Excavator Special Notes
Options / Pricing / Availability
Call for price
Core Dimensions Height: 32.5625"
Width: 29.5"
Depth: 2.25"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 2" (Left) Outlet: 2" (Right) Oil Cooler: None OE Numbers
450089
YB05P00001S001 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450091 - Johnson 4000 Sweeper Radiator Special Notes
Options / Pricing / Availability
Call for price
Core Dimensions Height: 27.5"
Width: 25"
Depth: 4.125"
Overall Height: -
Description Product Type: Radiator Filler Neck: None Oil Cooler: None OE Numbers
450091
9D0969914 327191 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450092 - Johnson Sweeper Aluminum Radiator Special Notes
Options / Pricing / Availability
Call for price
Core Dimensions Height: 33"
Width: 25.5"
Depth: 4.125"
Overall Height: -
Description Product Type: Radiator Filler Neck: None Oil Cooler: None OE Numbers
450092
327192 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450094 - Industrial Radiator Special Notes
Options / Pricing / Availability
Core Dimensions Height: 12"
Width: 11"
Depth: 1.5"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: None Inlet: 1.5" (Left) Outlet: 1.5" (Right) Oil Cooler: None OE Numbers
450094
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450096 - Case / Volvo CE Radiator Special Notes
Options / Pricing / Availability
Call for price
Call for price
Core Dimensions Height: 22.5625"
Width: 22"
Depth: 4.1875"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: None Inlet: 1.75" (Right) Outlet: 2.25" (Right) Oil Cooler: None OE Numbers
450096
450096ST MN42200041012N MN42200041212N MN42213286703C 87410096 87410098 87416657 MN22200019912N 87544110 53595 87576643 87310155 84497735 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450098 - Doosan Forklift Radiator Special Notes
Options / Pricing / Availability
Call for price
Core Dimensions Height: 18.625"
Width: 16.75"
Depth: 2.25"
Overall Height: -
Description Product Type: Radiator Orientation: Crossflow Filler Neck: Right Inlet: 2" (Left) Outlet: 2" (Right) Oil Cooler: Right OE Numbers
450098
A403533 A403577 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450099 - Komatsu Excavator Radiator Special Notes Please verify extra 5/8" connection next to the petcock before ordering.
Options / Pricing / Availability
Call for price
Call for price
Core Dimensions Height: 32.5625"
Width: 29.5"
Depth: 2.25"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 2" (Right) Outlet: 2" (Left) Oil Cooler: None OE Numbers
450099
20Y0331111 212029 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450100 - Multiquip / Volvo TAD520GE Radiator Special Notes
Options / Pricing / Availability
Call for price
Core Dimensions Height: 42.375"
Width: 26.3125"
Depth: 2.25"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: None Inlet: 2.5" (Right) Outlet: 2.5" (Left) Oil Cooler: None OE Numbers
450100
V20585499 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
www.activeradiator.com Call today to Order
450101 - Perkins Stationary Diesel Engine Radiator Special Notes
Options / Pricing / Availability
Call for price
Call for price
Core Dimensions Height: 22"
Width: 22"
Depth: 2.25"
Overall Height: -
Description Product Type: Radiator Orientation: Downflow Filler Neck: Top Inlet: 2" (Left) Outlet: 2.25" (Left) Oil Cooler: None OE Numbers
450101
AR36677 MNY202248014F0P 2485B263 245984 MNY20226501E 2485B269 MNY20224801F RB263B 245982 245984 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
